Additional for MB trucks
License GS2
 |
|||
The license GS2 allows to Read / Write automatic gearbox GS2 (EPS3) ECU flash/eeprom.
Electronic Control Unit and type:
GS2 / EPSIII made by WABCO
Type:
MEMO – memory reading and writing for control unit replacement and internal firmware repair (rewrite).
Functionality:
1. Read / Write ECU memory thru DirectConnect 2U (or 2M) tool in standalone mode.
2. Standalone diagnostics.
Supports GS2 (EPSIII) ST10F276 version:
- FLASH: ST10F276, 832 KB
- EEPROM A: 93C86, 2 KB
Supports GS2 (EPSIII) C167CS version:
- FLASH: C167CS
- EEPROM A
Hardware and cables are not included in the package.
Requirements (not included):
VEI V6 device
DirectConnect 2U or 2M tool
DC2-GS2 cable
DC2-ISP6 cable for BSL mode
Software version 6.0 or newest
Laboratory power supply 24VDC 3A
Important:
Do not write Flash and Eeprom to the different GS hardware versions!
GS will be damaged and will be needed to open GS for BSL recovery.
Truck Explorer shows a hardware version you have connected (example: 04 to 06).
| |||
